how long will a 12v battery last with an inverter？
Calculating Your Essential Battery Runtime
To plan any off-grid, mobile, or backup power system, you must first understand how long a 12V battery will last with an inverter. This crucial calculation determines your autonomy—the hours you can run essential appliances without external power. Simply knowing your battery’s Amp-Hour (Ah) rating is not enough. Three key technical factors—battery chemistry, inverter efficiency, and your effective power draw—influence the actual runtime. This guide provides a straightforward, formula-based approach to accurately predict your runtime, ensuring you avoid unexpected power loss.
The Core Formula: From Amp-Hours to Running Time
To accurately determine runtime, you must first convert your battery’s storage capacity from Amp-Hours (Ah) to Watt-Hours (Wh), which is a direct measure of energy.
Step 1: Calculate Total Battery Energy (Wh)
The Watt-hour capacity represents the total energy stored in the battery.
Total Watt-Hours (Wh) =Battery Amp-Hours (Ah) × Battery Voltage (V)
For a standard 12V, 100Ah battery, the calculation is simple:
Total Wh = 100Ah × 12V =1200Wh
Step 2: Calculate Basic Runtime (Hours)
The basic runtime is calculated by dividing the total Watt-Hours by the total wattage of the load you plan to run.
Basic Runtime (Hours) = Total Watt-Hours (Wh) / Total Load Wattage (W)
If your load is 200 Watts (e.g., a small fridge and a few lights):
Basic Runtime = 1200Wh / 200W = 6 Hours
This 6-hour figure is a starting point, but it’s fundamentally flawed. It does not account for real-world inefficiencies and safety limits.
The Essential Correction Factors for Accuracy
Accurate 12V battery runtime calculation requires adjusting the basic formula using three critical factors that reduce the theoretical runtime.
3.1 Factor 1: Depth of Discharge (DoD)
The Depth of Discharge (DoD) is the most significant factor affecting runtime. It is the percentage of the battery’s capacity that is safely used.
- Lead-Acid/AGM Batteries: To maintain lifespan, these should not be discharged below 50% DoD. Usable capacity is only 50%.
- LiFePO4 Batteries: These can safely be discharged to 80%–90% DoD with minimal impact on cycle life. Usable capacity is substantially higher.
You must multiply your Total Wh by the maximum allowable DoD (e.g., 0.5 for lead-acid or 0.8 for LFP).
3.2 Factor 2: Inverter Efficiency
Your inverter converts the DC power from the battery into usable AC power for your appliances. This conversion is not 100% efficient; some energy is always lost as heat.
High-quality Pure Sine Wave Inverters typically operate at 85% to 92% efficiency under load. Using 85% is a safe, conservative estimate for your calculation.
You must multiply your adjusted Wh by the inverter efficiency factor (e.g., 0.85).
3.3 Factor 3: Wiring and Temperature Losses
While less significant, energy is also lost through resistance in the wiring and extreme temperatures. For most standard setups, we often use a general 5% buffer to account for these minor losses.
The Definitive Runtime Formula
Incorporating the essential correction factors, the most accurate formula to determine how long will a 12V battery last with an inverter is:
Accurate Runtime (Hours) =(Battey Ah × 12V) × DoD × Inverter Efficiency / Load Wattage
Example Calculation (100Ah Battery, 200W Load):
Case A: Traditional Lead-Acid Battery (50% DoD, 85% Efficiency)
Runtime = (100Ah × 12V) × 0.50 × 0.85 / 200W
Runtime = 1200Wh × 0.425 / 200W = 2.55 Hours
Case B: LiFePO4 Battery (80% DoD, 90% Efficiency)
Runtime = (100Ah × 12V) × 0.50 × 0.90 / 200W
Runtime = 1200Wh × 0.72 / 200W = 4.32 Hours
The result is clear: simply by choosing the superior battery chemistry, you gain over 69% more runtime from the same nominal 100Ah capacity. This illustrates why the battery type is critical.
Why LiFePO4 is the Smart Choice for Runtime
The dramatic difference between Case A and Case B emphasizes that Amp-Hours alone are misleading. The high usable capacity of Lithium Iron Phosphate (LiFePO4) is the key differentiator for extended runtime.
LiFePO4 batteries allow for deep, reliable cycling to 80% DoD, safely maximizing the power you paid for. Furthermore, they maintain a more stable voltage output during discharge, which contributes to the higher efficiency of the inverter.
When evaluating your long-term energy needs, the higher initial cost of LiFePO4 is quickly justified by the increased runtime, reliability, and cycle life (typically 6,000+ cycles versus 500 cycles for lead-acid).
Practical Tips for Maximizing Your Runtime
To get the most out of your solar power lithium battery storage system, follow these practical steps:
- Reduce AC Load: Where possible, use DC-powered appliances (like 12V LED lights) directly from the battery to bypass the inverter entirely, eliminating conversion loss.
- Choose High-Efficiency Inverters: Always select a high-quality Pure Sine Wave inverter with a proven efficiency rating of $90\%$ or better.
- Monitor DoD: Use a high-quality Battery Monitor or a smart BMS to ensure you never exceed your battery’s safe DoD limit, protecting its warranty and longevity.
- Wire Gauge: Use correctly sized, thick wires for your connections to minimize resistive losses, ensuring maximum energy reaches your inverter.
Get Reliable Energy Solutions
Knowing how long a 12V battery will last with an inverter depends on a precise calculation that accounts for DoD and efficiency. By upgrading to high-performance LiFePO4 batteries and efficient inverters, you secure reliable, extended runtime.
Don’t settle for theoretical runtimes. Calculate the actual capacity your system delivers.
